Army Research Laboratory, UF team up to develop model for lighter armor

ABERDEEN PROVING GROUND, Md. University of Florida and U.S. Army Research Laboratory (ARL) researchers teamed up to develop new light-weight ceramic materials that resist fracture. The end result can be used for personal protection and Army systems.

The UF researchers developed a new model that describes the granular material response more accurately by studying the stress state at which a variety of ceramics fail as reported in the literature by various research teams.

In their research, they are focusing on failure through cracking; the material eventually disintegrates into a granular-like state through a process called comminution.

"While various ceramic materials possess high hardness, they fail easily when pulled apart. That is, when subjected to tensile forces. The amount of tension that these materials can withstand before failure, is a small fraction of the compression they can withstand. As a result, high velocity impact of bullets and fragments causes extensive cracking and fragmentation of the material, reducing its ability to fully utilize its superior hardness to resist complex stress states generated by the impact event," explains Dr. Sikhanda Satapathy, of ARL's Soldier Protection Sciences Branch.

The ARL and the UF team collaborated to employ this improved granular response model in conjunction with a dynamic cavity expansion modeling framework to capture the response of ceramics to the complex impact-induced stress state that includes compression, tension, and shear. The dynamic cavity expansion modeling framework uses the pressure required to expand a cavity in an intact material to characterize its ability to resist deep penetration. This pressure, of course, is dependent on how the material responds to compression, tension and shear forces.

Side image of a laboratory projectile impacting a ceramic disk backed by polycarbonate captured using high speed cameras. Photo by Army Research Laboratory

Due to the applicability of this new model to a broad class of ceramics, the need for expensive experiments to characterize penetration response is significantly reduced. The new penetration model improves the understanding of how brittle ceramic responds to high impact stress by fracturing and comminuting to granular like material, and increases modeling ability of penetration events.

The improved model has been shown to better predict the resistance of a wide range of ceramic targets when shot at by a long-rod projectiles at velocities up to 3km/s. The important material parameters for penetration performance of a ceramic target have been identified through this collaborative effort, which will guide how the failure processes in ceramic can be controlled through improved material design or through a multi-materials systems approach.

The research will appear in the International Journal of Solids and Structures.
